GPFCN750/250A400
The GPFCN-750/250A400 is a smart power system: its 153.6kW-rated smart power station (2300×1750×2400mm) pairs with a 500kW-service intelligent firewood unit (5500×2200×2450mm) for reliable, well-sized power support. To solve the pain points such as high fuel consumption of diesel generators, untimely load response, and weak power grid adjustment ability, our company combines rail transit hybrid technology to develop a smart power station with diesel generators and energy storage as the core, and uses microgrid technology to realize grid-connected operation of photovoltaic, utility, and other energy systems. It provides energy saving, high efficiency, and a low-carbon distributed power supply for users in different scenarios. As part of SinoMac, SinoGen also provides complete power supply solutions that are powered by DCEC、CCEC、SDEC、CAT, our ranges of products including open type generator sets, silent-type generator sets, super-silent-type generator sets, mobile trailers, complete power truck and complete power cars for railway applications. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from troubleshooting to overhaul technical support.
Advantages of GPFCN750/250A400 Fuel Saver
-
Compared to the traditional diesel generator set, it can save at least 30% of fuel. By using a national Il emission diesel engine, the station can reduce the combustion emissions of diesel engines.
-
The diesel generator set can be shut down for a long time, and the operation under low load and overload can be avoided to increase the service life of the diesel generator set.
-
The fuel saver can not only be used as a common power supply output equipment, but also can realize the power expansion, and energy grid-connection, and other functions.
-
The fuel saver set relies on its powerful computing ability to enable the energy storage to respond to sudden changes in power and sudden cuts. Additionally, the fuel saver set can absorb and eliminate transient interference and harmonics in the power grid, thereby improving the quality of the power supply.
Technical Specifications
Basic Introduction of GPFCN750/250A400 Fuel Saver
| Fuel Saver Model: | GPFCN750/250A400 |
| Total Power: | 750 kW |
| Rated Output Voltage: | 400 Vac |
| Rated Output Frequency: | 50 Hz |
| BESS Power: | 250 kW |
| Service power: | 500 kW |
| Size: | 2300×1750×2400mm |
| System noise(dB): | ≤80@7m |
| Class of protection: | IP54 |
Model |
Total Power |
Rated Output Voltage |
Rated Output Frequency |
Size |
| GPFCN450/250A400 | 450 | 400 | 50 | 2300×1750×2400mm |
| GPFCN550/250A400 | 550 | 400 | 50 | 2300×1750×2400mm |
| GPFCN610/250A400 | 610 | 400 | 50 | 2300×1750×2400mm |
| GPFCN650/250A400 | 650 | 400 | 50 | 2300×1750×2400mm |
| GPFCN750/250A400 | 750 | 400 | 50 | 2300×1750×2400mm |
| GPY-650A400 | 650 | 400 | 50 | 6058×2438×2830mm |
| ——END—— | ||||
Product Data of GPFCN-750/250A400 |
|||
| Model Number | GPFCN-750/250A400 | Peak Power (kVA) | 250 |
| Rated Power (kW) | 153.6 | Electricity (kWh) | 153.6 |
| Standby Power (kW) | 550 | Service Power (kW) | 500 |
| Sustained Power (kW) | 400 | Sustained Power (kW) [Combined] | 553.6 |
| Rated Power (kW) [Combined] | 653.6 | Peak Power (kVA) [Combined] | 800 |
| Smart Power Station Size (mm) | 2300×1750×2400mm | Smart Firewood Unit Size (mm) | 5500×2200×2450mm |
| ——END—— | |||

Specifications of GPFCN-750/250A400 |
|||
| Rated Output Voltage (Vac) | 400 | Rated Output Frequency (Hz) | 50 |
| Output Phase Number | three-phase four-wire | Power Supply System | TT |
| Working Ambient Temperature (℃) | -20-45 | Storage Ambient Temperature (℃) | -20-50 |
| Operating Relative Humidity | 5%-95% | System Noise (dB) | ≤80@7m |
| Protection Class | IP54 | ||
| ——END—— | |||
Note: All Above Data are Just for Referenece, All Data Might Change Without Notices or Update, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
